Kitchen Hood: How to Choose

By
Newmatic Best Kitchen Hoods

YOUR KITCHEN. FRESH.

BENEFITS..

HEALTH
Cooking with a flame uses up oxygen rapidly & if not replenished, carbon monoxide may cause asphyxia. Your hood ensures fresh air is replenished for your safety.
Hood Collection
SAFETY
Cooking with a flame uses up oxygen rapidly & if not replenished, carbon monoxide may cause asphyxia. Your hood ensures fresh air is replenished for your safety.
Select a Hood
DECORATIVE
Your kitchen hood is the centerpiece of the kitchen. Not only a useful appliance but often a talking coversation piece.
Choose a Hood
QUALITY OF LIFE
Smelling the odour from last night's dinner in the morning? Your kitchen hood ensures that cooking odour is eliminated for a pleasant environment
Order one Today
TIME SAVING
No more residual steam & grease means less time for cleaning up & more time for the family
Get a Hood Here!
Previous slide
Next slide

Newmatic Advantage

FREE INSTALLATION

Managed by our skilled technicians

FREE DELIVERY

Within Dar es Salaam (80KM Radius)

TECHNICAL SUPPORT

Parts & service within 48 hours

5 YEARS WARRANTY

On Motor

POWER EXTRACTION

Twin metal propellers delivering 760m3/hr airflow

LED LAMPS

Energy saving & ultra durable

How to Choose a Kitchen Extractor Hood

Newmatic island wall undermount kitchen

TYPE OF MOUNT

The way the kitchen hood is mounted is a good place to start. Wall-mounted hoods are the most common, applicable to more than 50% of kitchens. Ceiling-mounted or island hoods serve large, island-style kitchen designs. Undermount or integrated hoods have lower airflows and are usually for smaller kitchens to maximize kitchen cabinet space.

Newmatic kitchen hood dimensions

SIZE (WIDTH)

The size of the chimney hood refers to the width; this is determined by the width of the stove that the hood serves. The most common sizes of stoves are 90 & 60cm. Less common are 30cm or anything between 70 – 80cm. The width of the hood should at least be the width of the stove to ensure the capture of cooking fumes, so hoods of 90 & 60cm widths are the most common. Hoods of widths 70, 80 & 100cm are available but not common.

Diagram showing the differences between ducted and recirculating mode.

DUCTED OR RE-CIRCULATING

Hoods are originally designed to operate in the ducted mode where exhaust & cooking fumes are expelled followed by reciprocal intake of fresh air into the kitchen. However, in certain situations where it is not possible to do so, some hoods may be operated in re-circulating mode by adding charcoal filters. In the re-circulating mode, the hood works more like an air cleaner where the aluminum filters condense residual grease & steam, and charcoal filters absorb cooking odor.

Newmatic chimney hood motor blowers

BLOWERS

The blower is the heart of the hood just like the engine of a car. It consists of a motor, propeller/s enclosed in a housing.

The housing & propellers may be made of plastic (fire-resistant PP) or steel, the latter offering high rigidity, high pressure & no risk of deformation from heat. Plastic blowers & propellers are easy to manufacture & are less noisy.

The types of motors used in a blower may be of the following;

  • DC – expensive, most quiet, high energy efficiency, offers step-less control

  • AC – most common, high torque, standard efficiency, extreme durability

  • Shaded pole – low cost, poor energy efficiency that gets worse with age, poor airflow

Powerful Twin Propellers for all Newmatic Hoods

AIRFLOW

The airflow refers to the extraction power of the hood and denoted in m3/hr. The airflow of chimney hoods may range from 150~1200m3/hr.

As a general guide, choose airflow for your kitchen as follow:-

  • Small kitchens up to 10 sqm : 150~350 m3/hr

  • Medium kitchens 11~20 sqm : 350~650 m3/hr

  • Large kitchens bigget than 25 sqm : 750~1200m3/hr

In recirculating mode, airflow numbers of a chimney hood is mostly irrelevant.



Newmatic chimney hood LED lamps

ILLUMINATION

  • Stainless steel – Usually of the 430 grade & 0.6-0.9mm gauge, is a very durable material. The hairline finishing is attractive but delicate (not scratch proof)

  • Painted steel – Used in low-cost hoods, powder-coated steel is not durable at all under the conditions of a working kitchen.

  • Tempered glass – The best material used in hood canopies. An endlessly durable material that looks new even after years of use and is very easy to clean.

  • Non-tempered glass – A very dangerous practice in the industry to reduce cost and make a cheap product look expensive. Non-tempered glass breaks easily, large shards falling from a height may cause serious injury

Newmatic chimney hood types of switchs

CONTROLS

The hood may be controlled by mechanical or electronic type switches.

  • Touch –  Is the best for high-end products. Hermetically sealed from steam & fumes of the kitchen environment making it very durable. Sleek looks & feature functions like remote control, timer, dimming.

  • Electronic– It works like the touch control except for the protruding buttons. Cooking fumes & steam may penetrate to reduce its useful life. The buttons make cleaning less convenient.

  • Mechanical push button – A simple, easy to operate switch used in mid to low range hoods. Not sophisticated but very durable.

  • Mechanical slider switch – Simple switch in low-end hoods. Difficult to operate with greasy finger, not durable at all due to design.

Newmatic stainless steel for chimney hood

CHASSIS MATERIAL

  • Stainless steel – Usually of 430 grade & 0.6-0.9mm gauge, it is a very durable material. Hairline finishing is attractive but delicate (not scratch proof)

  • Painted steel – Used in low-cost hoods, powder-coated steel is not durable at all under the conditions of a working kitchen.

  • Tempered glass – The best material for hood canopies. Endlessly durable, looks new even after years of use, and is very easy to clean.

  • Non-tempered glass – A dark practice in the industry to reduce cost & make a cheap product look expensive. Non-tempered glass breaks easily, large shards falling from a height may cause serious injury

Newmatic chimney hood filters

PITFALLS & TELL TALE SIGNS

  • Plastic latch on aluminum filters: If you remove a pot from the gas stove without switching off the flame, this part will melt in a minute

  • Plastic lamp cover over incandescent bulb: The lamp cover will melt should you forget to switch off the lamp.

  • Hood is very light: cutting corners with thin material & subsituted parts with plastic

  • Grease or charcoal filters in fibre sheet: A fire hazard when saturated with grease
